OSI Wi-Fi Alarm System (GEN2) Specifications
Alarm System Display
Product name | OSI-ALM-G2KIT alarm system |
Display screen | 7" Display (4:3) 1024 x 600 High Resolution (clock/arm/disarm/rechargable battery and Wi-Fi signal indicators) / Anti finger print display: |
APP function | App remotely arm/disarm Parameter setting and accessory management Rename defense zone |
Learning/storage location | Support up to 100 learning/storage location for remote control and wireless detector |
WiFi Standard | IEEE802.11b/g/n 2.4G Band |
Siren | Built-in 120db |
Wired Zones | Supports 8 Wired Zones: In a wireless alarm system, "wired zones" are specific areas with traditional wired sensors like door/window contacts, connected to the main control panel via wires. This hybrid setup combines wired and wireless components for comprehensive security. |
Daily operations | Remote control, Mobile phone APP and Display |
Languages | Support 10 languages: English / Nederlands / Spanish / Russian / French / Polish / German / Italian / Portuguese / Chinese |
Back-up Battery time | 3.7 5000mAH (lasts 24 hours during power failure) |
APP | Android and IOS compatible |
Other Compatibility | Google Assistant and Alexa (voice control and automation control) |
Input Power | DC12V 1A external cable DC5V 2A Type-C USB |
Working Power Consumption | 5W |
Working Temperature | -10°C~+50°C |
Reletive Humidity | <95% (no condensation) |
How many Sirens can be connected? | 183mm x 135mm x 18mm |
How many Contact and Motion sensors can be connected to the OSI Gen 2 Alarm System? | 160 |
How many Keypads can be connected? | 6 |
Product Size | 183mm x 135mm x 18mm |
Motion Sensor
Battery Specification | AA Battery X 2 (included in each). Lets you know when battery is low |
Standby Current | 10uA |
Alarm Current | 15mA |
Detection Angle | 110° |
Working Temperature | -10°C~+50°C |
Reletive Humidity | <95% (no condensation) |
Wireless Parameters | 433MHz, eV1527 |
How many Contact and Motion sensors can be connected to the OSI Gen 2 Alarm System? | 160 |
Product Size | 50 x 92mm |
Contact Sensor
Battery Specification | 2 CR2450 Coin Batteries (included in each) Battery Life is 5 Years. Lets you know when battery is low |
Standby Current | 1uA |
Alarm Current | 20mA |
Working Temperature | -10°C~+50°C |
Reletive Humidity | <95% (no condensation) |
Wireless Parameters | 433MHz, eV1527 |
How many Contact and Motion sensors can be connected to the OSI Gen 2 Alarm System? | 160 |
How many Contact and Motion sensors can be connected to the OSI Gen 2 Alarm System? | 160 |
Product Size | 70×31.5×15.5mm |
Wireless Strobe Siren
Power Supply | AC100~240V plugs directly into wall outlet. no cable! |
Built-in Battery | 3.7V 500mAh |
Standby Current | 10mA |
Alarm Current | 200mA |
Standby Current | 10mA |
Alarm Current | 200mA |
Wireless Parameters | 433MHz, eV1527 |
Audio | 120db |
Receiving Distance | 120m (open area) |
How many can be connected to the OSI Gen 2 Alarm System? | 15 |
Product Size | 90 x 90 x 45mm |
Remote Control
Battery Specification | CR2032 X 1 (included in each) |
Standby Current | 1uA |
Alarm Current | 10mA |
Detection Angle | 110° |
Working Temperature | -10°C~+50°C |
How many can be connected to the OSI Gen 2 Alarm System? | 6 |
Wireless Parameters | 433MHz, eV1527 |
Product Size | 60 x 39.7 x 12mm |
